Here are some pictures of Take 3s most popular trailer, the Ultra lite 48. The base model weighs in at 5180# and can be ordered with a GVW of 12000 to keep your truck and trailer combination under the 26,001 CDL threshold.
Take 3 Ultra-Lite 48 Standard model
96" wide with rolled edge deck
49' load deck
Take 3 Exclusive perforated Soft-Tie Deck System w/12 Soft-Tie Wheel Lashing Assemblies
2 Dexter 7K Axles on Heavy Duty Spread Axle Suspension
7'5" 7K Aluminum Ramps on Side Hangers w/stainless locks
24" X 18" X 18" Aluminum RKI Toolbox
Spare 16" Aluminum Wheel/Tire LED Lighting Package
2 5/16" adj. hitch w/ball coupler
12,000-14,000 GVWR (Must be specified before delivery)
Popular options on this model are G Rated Tires and a 2nd Toolbox.
The Ultra-lite 48 low pro is designed for trucks with 5th wheels and no factory beds. This design allows the top of the trailer to be lower and allows for taller vehicles. It can be purchased as a trailer hauler as well. The base model weighs in at 5300# and can be ordered with a GVW of 12000 to keep your truck and trailer combination under the 26,001 CDL threshold. Aluminum wheels, aluminum spare, and aluminum ramps are standard.
Take 3® Standard 5 CAR HD
The 5 CAR HD comes fully equipped and ready to haul and leaves no room for comparisons.
•Kingpin ONLY (2” SAE FORGED)
•Ride height 42” – 48” vehicle specific
•Clearance at highest point of adjustment is 89”
•Clearance from lower deck floor to bottom of top deck is 68”
•Upper deck length is 49’ up to 51’ with front flip ramp extensions
including the hydraulic rear platform w/ wireless remote
•Upper deck width is 96”
•Lower deck width in front of axles is 84” and behind the axles is 96”
•Hydraulic lift rating is 12,000 Lbs.
•10’ dovetail
•25,999 – 30,000 lb. GVWR (FET may apply)
•3 – 10,000 lb. Dexter Torsion Axles w/ Electric over Hydraulic drum brakes on all axles
Stock # 540033NC MINIMUM TOW VEHICLE WITH 19,500 LB GVWR TRAILER SHOULD MAINTAIN A 48" RIDE HEIGHT Kingpin ONLY (2" SAE FORGED) Ride height 42" - 48" vehicle specific Clearance at highest point of adjustment is 89" Clearance from lower deck floor to bottom of top deck is 68" Upper deck length is 49' up to 51' with front flip ramp extensions including the hydraulic rear platform w/ wireless remote Upper deck width is 96" Lower deck width in front of axles is 84" and behind the axles is 96" Hydraulic lift rating is 12,000 Lbs....
Stock # 540040NC MINIMUM TOW VEHICLE WITH 19,500 LB GVWR TRAILER SHOULD MAINTAIN A 48" RIDE HEIGHT Kingpin ONLY (2" SAE FORGED) Ride height 42" - 48" vehicle specific Clearance at highest point of adjustment is 89" Clearance from lower deck floor to bottom of top deck is 68" Upper deck length is 49' up to 51' with front flip ramp extensions including the hydraulic rear platform w/ wireless remote Upper deck width is 96" Lower deck width in front of axles is 84" and behind the axles is 96" Hydraulic lift rating is 12,000 Lbs....
